415276-2 - TE Connectivity
TE Connectivity
415276-2
0-0415276-2
0-0415276-2
Other Connectors
Miscellaneous Micro Min Surfa
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- RF Connector Interface:F Series
- Connector Style:Jack
- Connector System:Cable-to-Board
- Sealable:No
- Connector & Contact Terminates To:Printed Circuit Board
Configuration Features
- Port Configuration:Single Port
- Number of Positions:1
- PCB Mount Orientation:Right Angle
- Number of Coaxial Contacts:1
Electrical Characteristics
- Impedance(O):75
Body Features
- Body Material:Zinc
- Body Plating Material:Tin
Contact Features
- Center Contact Plating Material:Tin
- Center Contact Base Material:Beryllium Copper
Termination Features
- Termination Method to Printed Circuit Board:Through Hole
Mechanical Attachment
- RF Connector Coupling Mechanism:Threaded
- Connector Mounting Type:Board Mount
- RF Contact Captivation Method:Mechanical
- Detent:With
Dimensions
- RF Connector Mated Outer Diameter (Approximate):9.65mm[.38in]
- Height above PCB:12.85mm[.506in]
- PCB Tail Length:3.81mm[.15in]
Usage Conditions
- Operating Temperature Range:-55 – 85°C[-67 – 185°F]
Operation/Application
- Operating Frequency(GHz):1
Packaging Features
- Packaging Method:Carton
Other
- Dielectric Material:Polymethylpentene
- Comment:Connector will accept center conductor diameter range of .56 – 1.19 [.022 – .047].
Accessories
Accessories
No details available.
