1-353293-6 - TE Connectivity
TE Connectivity
1-353293-6
1-0353293-6
1-0353293-6
PCB-Connectors
Mini CT 1,5 Buchsenstecker
16 polig, AWG 28-26, grau
16 polig, AWG 28-26, grau
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- Connector System:Wire-to-Board
- Sealable:No
- Connector & Contact Terminates To:Wire & Cable
- Connector Style:Receptacle
Configuration Features
- Number of Positions:16
- Number of Rows:1
Body Features
- Color:Natural
Contact Features
- Contact Current Rating (Max)(A):2
Termination Features
- Termination Method to Wire & Cable:Insulation Displacement Crimp (IDC)
Mechanical Attachment
- Mating Retention:With
- Mating Retention Type:Lock
- Connector Mounting Type:Cable Mount
- Mating Alignment:With
Housing Features
- Centerline (Pitch):1.5mm[.06in]
Usage Conditions
- Operating Temperature Range:-30 – 105°C[-22 – 221°F]
Operation/Application
- Circuit Application:Power & Signal
Accessories
Accessories
No details available.
