1-1410297-5
1-1410297-5
1-1410297-5
Other Connectors
MINI POWER MODULES
Datasheets
Datasheets
Technical Characteristics
Technical Characteristics
Product Type Features
- Housing Type:Receptacle
- Product Type:Guide Assembly
- Connector System:Board-to-Board
- Connector & Contact Terminates To:Printed Circuit Board
Configuration Features
- Number of Positions:1
- PCB Mount Orientation:Right Angle
- Key Orientation:180°
- Stackable:Yes
Electrical Characteristics
- Operating Voltage(VAC):48
- Power Contact Voltage Rating(VDC):48
Contact Features
- Contact Base Material:Phosphor Bronze
- Contact Length(mm):14.06
- Contact Current Rating (Max)(A):5, 20
- Contact Termination Area Plating Material:Silver
- PCB Contact Termination Area Plating Material Finish:Semi-Bright
Termination Features
- Termination Method to Printed Circuit Board:Through Hole - Screw
Mechanical Attachment
- PCB Mount Retention Type:Screw Mount
- PCB Mount Retention:With
- Guide Hardware:With
- Connector Mounting Type:Board Mount
- Mating Alignment:With
- Mating Alignment Type:Keyed
Housing Features
- Housing Material:Zinc Alloy
- Housing Plating Material:Nickel
Dimensions
- PCB Hole Diameter(mm):3.96
- Height(mm):18.4
- Width(mm):10.7
- Stack Height(mm):18.4
- Length(mm):31.88
Usage Conditions
- Operating Temperature Range:-55 – 105°C[-67 – 221°F]
Operation/Application
- Circuit Application:Power
Packaging Features
- Packaging Method:Package
Other
- Comment:Keyed.
Accessories
Accessories
No details available.
